| SW 100 |
High Availability
Computing & Security Solutions |
| Embedded
Video Capture Board |
|
|
Key Features |
| |
|
|
|
Conexant BT878 capture chip |
| |
1-4
video-in channels (4 composite or 3 composite and one S-video) |
| Video Server |
local
viewing with monitor or TV (optional TV encoder) |
| |
National
low power 233/266 MHz GXM |
| Digital Video Recorder |
Integrated
10/100 Mbps Ethernet |
| |
8
MB M System DOC soldered on-board |
| Child / Elderly Monitoring |
16/32
MB SDRAM soldered on-board |
| |
parallel
and serial port |
| Shop / Production Line Monitoring |
44-pin
notebook HDD interface |
| |
5-pin
header for PS/2 keyboard and mouse |
| |
144x117
mm (width/depth) |
| |
|
